User Guide

16
SPARES LIST (continued)
Description Part Number Reference
Pressure Recorders:
Tailpiece St/St 2” BSP 22251 / 9
Tailpiece St/St a” BSP 17600 / 01
Tailpiece Brass 2” BSP 22251 / 22
Tailpiece Brass a” BSP 16992 / 51
Nut St/St 2” BSP 22251 / 10 Fig. 2
Nut St/St a” BSP 17599 / 01
Nut Brass 2” BSP 22251 / 20
Nut St/St a” BSP 16692 / 01
Fibre washer 2” BSP 22 / 745
Fibre washer a” BSP 22 / 746
Programme Controllers:
Chart carrier 17271 / 26
Chart clamp nut 17271 / 27
Cam clamp nut 17271 / 6 Fig. 8
Cam blank 17271 / 29
Relay (electrical) – 5 amp 87294
3 amp 600492
Setting pointer clamp nut 15321 / 245
Stud – panel mounting 100013 Fig. 2
Temperature and Humidity Recorders:
Element guard 22 / 401
Wick for Wet & Dry Bulb Water Bath 100016 Fig. 10
Window glass 15 / 204
Window perspex 15 / 204C
Zero screw ‘S’ 15 / 228 Fig. 3
Made Up kits:
Relay type 2400 (Part No. 600169) is no longer available as a spare part and is
replaced by one of the following relay kits.
Single relay replacement:
(200/250V, 50 or 60 Hz supply) 15321 / 542 / 1
(100/120V, 50 or 60 Hz supply) 15321 / 542 / 2 Refer to
Double relay replacement: Service Aid
(200/250V, 50 or 60 hz supply) 15321 / 543 / 1 No. 15321 / 545
(100/120V, 50 or 60 Hz supply) 15321 / 543 / 2
For information on other Spare Parts or Kits contact British Rototherm.
