Controller Functionality
AYC-Ex5 and AYC-T65 Installation and Programming Manual 39
passes. After this time, the door is locked even if the REX button
is not released.
Fail Safe Operation – From the moment the REX button is
pressed, the door is unlocked until the REX button is released,
plus the Lock Strike Release Time. In this case, the Lock Strike
Relay only begins its count down once the REX button is released.
6.8 Secure Application Appurtenances
Rosslare’s secure application appurtenances are designed for use with
Rosslare's secured series standalone access control units, including the
AYC-Ex5 series and the AYC-T65. These units are designed to operate
indoors and installed within the secured premises. The units must be
used with one of Rosslare’s secure application appurtenances, which
provide Lock Strike output and REX Input.
Both units communicate through a proprietary Rosslare protocol,
which provides a secure link between the AYC-Ex5 or the AYC-T65
and the appurtenances. This in turn activates the door lock.
The units also function as the power supply for the AYC-Ex5 and
AYC-T65; they also contain a speaker connection for all sounder
abilities.
For more information see the specific Appurtenances Manual.
6.9 Programming the AYC-Ex5 and AYC-T65
Programming the AYC-Ex5 and AYC-T65 is done solely via the unit's
keypad driven Programming Menu System. To reach the
Programming Menu System, the unit must first be put into
Programming mode (see Section 6.9.1).
During a unit’s manufacturing process, certain codes and settings are
pre-programmed. These settings are the called the default factory
settings.
Table 4 shows the names of all the AYC-Ex5 and AYC-T65 Controller
menus. It also shows of all the default factory codes and settings for
the units.
