Controller Functionality
AYC-Ex5 and AYC-T65 Installation and Programming Manual 35
Secure user
A Secure user must have a Primary and Secondary code
programmed; the two codes must not be the same. The Secure
user can gain access when the unit is in any of its three modes of
operation. In Normal mode, the Secure user must use their
Primary code to gain entry. In Secure mode, the Secure user must
present both the Primary and Secondary codes to gain entry.
Master User
A Master user must have both Primary and Secondary codes
programmed with the same PIN code. The Master user can gain
access during any mode of operation by presenting their PIN code
once to the controller. (The Master user is convenient but is less
secure than a Secure user.)
6.2 Modes of Operation
The AYC-Ex5 and AYC-T65 has three modes of operation:
6.2.1 Normal Mode
The Mode LED is green.
Normal mode is the default mode. In Normal mode the door is locked
until a Primary code is presented to the controller. Special codes such
as Lock Strike code and Auxiliary code are active in Normal mode. See
Sections 6.9.3 and 6.9.4 for more information on the Lock Strike and
Auxiliary codes.
6.2.2 Bypass Mode
The Mode LED is orange.
In Bypass mode, access to the premises is dependent on whether the
controller's Lock Strike Relay is programmed for Fail Safe Operation or
Fail Secure Operation. When the Lock Strike is programmed for Fail
Secure Operation, the door is locked until the "" button is pressed.
Mode/Transmit
Door/Program
Green
Mode/Transmit
Door/Program
Orange
