Controller Functionality
34 AYC-Ex5 and AYC-T65 Installation and Programming Manual
6. Controller Functionality
The AYC-Ex5 and AYC-T65 can function both as a reader and as a
controller. If the unit is connected to Rosslare’s secure application
appurtenance, it functions as a controller indicated by two beeps
immediately after power-on reset.
The Lock Strike and Auxiliary outputs, as well as the REX input, are
not located on the AYC-Ex5 or AYC-T65 unit, eliminating the
possibility of unauthorized entry to the restricted area.
The following explains how the unit functions as a controller.
6.1 Normal, Secure, and Master Users
The AYC-Ex5 and AYC-T65 accepts up to 500 users and provides
entry via the use of PIN codes and/or Proximity cards. Each user is
provided with two code memory slots, Memory Slot 1 (Primary code)
and Memory Slot 2 (Secondary code).
The PIN code length has several options. The PIN code length can be a
set number of 4, 5 or 6 digits or it can be a 4-8 digits option. When
choosing the 4- to 8-digit option, please note that you should either
enter zeros before the code, or press pound at the end (for example,
if your code is 12345, enter either 00012345 or 12345#).
Entering a code refers to either PIN or CARD depending on the
model you have.
The way in which the two memory slots are programmed determines
a user’s access level and also determines the way in which the unit
grants access in its three modes of operation. There are three user
levels:
Normal User
A Normal user only has a Primary code and is only granted access
when the unit is in Normal or Bypass mode.
