Reader Functionality
32 AYC-Ex5 and AYC-T65 Installation and Programming Manual
You hear three beeps.
The Program LED turns off
and the Transmit LED turns
red.
• The Facility code can be in the range of 000 to 255.
• The default Facility code is 0.
5.3 Setting the Backlight
1. Enter Programming mode.
2. Press “6” to enter Menu 6.
The Transmit LED turns red.
3. Enter the appropriate option number for the backlight option
that you wish to select:
“00” for always off
“11” for always on
“22
” for 10 sec. backlight after a key is pressed otherwise off
(Transmit LED also off)
“33” for 10 sec. backlight after a key is pressed otherwise
dimmed
The system returns to Transmit
mode.
You hear three beeps.
The Transmit LED turns red
Mode/Transmit
Door/Program
Red
Mode/Transmit
Door/Program
Green
Mode/Transmit
Door/Program
Red
Green
Mode/Transmit
Door/Program
Red
