Wiring Instructions
16 AYC-Ex5 and AYC-T65 Installation and Programming Manual
4. Wiring Instructions
The unit is supplied with a 60-inch (1.5 meter) pigtail, having a 6-
conductor cable. To connect the unit to the controller, perform the
following:
Prepare the unit's cable by cutting the cable jacket back 1¼ inches
and strip the wire ½ inch. Prepare the controller cable by cutting the
cable jacket back 1¼ inches and strip the wire ½ inch.
Splice the unit’s pigtail wires to the corresponding controller wires
and cover each connection.
Refer to Table 1 and to the wiring diagrams provided on the following
pages.
Table 1: Wiring Colors
Reader Controller Color Functionality
5~16 VDC 5~16 VDC Red +DC Input
Shield/Ground Shield/Ground Black Ground
Data 1/Clock C 1 White Communication
Data 0/Data C 2 Green Communication
LEDCTL AUX. IN Brown LED Control/Auxiliary Input
Tamper Tamper Purple Tamper
If the tamper output is used, connect the purple wire to the correct
input on the controller when used as a reader, or to a zone input of
an intruder alarm system when used as a controller.
Trim and cover all unused conductors.
