General Information
AYC-Ex5 and AYC-T65 Installation and Programming Manual 11
1.4 Ancillary Equipment
The following equipment is required to complete your installation:
1.4.1 Reader
Compatible host controller (not supplied) – UL listed access
control unit, such as model AC-215U
1.4.2 Controller
Secure application appurtenances (such as the PS-A25T, PS-C25T
or PS-C25TU secure controllers)
The controller connects to the following:
Electric lock strike mechanism or a magnetic lock device,
which implements fail safe (power to lock) or fail secure
(power to open) functions.
Request to Exit (REX) button – normally open type
Switch is closed when pressed.
Door monitor switch
Rosslare accessories can be found on
www.rosslaresecurity.com.
