User's Manual
Table Of Contents
- 1. General Information
- 2. Technical Specifications
- 3. Installation
- 4. Wiring Instructions
- 5. Reader Functionality
- 5.1 Transmit Mode
- 5.2 Programming the AYC- F/G/M60 Series
- Programming Menu
- Entering Programming Mode
- Exiting Programming Mode
- Selecting Keypad Transmission Format
- Keypad Transmission Format Option Number
- Option 1: Single Key, 6-Bit Wiegand (Rosslare Format)
- Option 2: Single Key, 6-Bit Wiegand Nibble and Parities
- Option 3: Single Key, 8-Bit Wiegand Nibbles Complemented
- Option 4: 4 Keys Binary + Facility Code, 26-Bit Wiegand
- Option 5: 1 to 5 Keys + Facility Code, 26-Bit Wiegand
- Option 6: 6 Keys BCD and parity bits, 26-Bit Wiegand
- Option 7: Single Key, 3x4 Matrix Keypad (MD-P64)
- Option 8: 1 to 8 Keys BCD, Clock & Data
- Option 9: Single Key, 4-bit Wiegand
- Selecting Proximity Card Transmission Format
- Changing the Programming Code
- Changing the Facility Code
- Setting the Backlight and Reader Format
- Return to Factory Default Settings
- Replacing a Lost Programming Code
- 6. Controller Functionality
- 6.1 Normal, Secure, and Master Users
- 6.2 Modes of Operation
- 6.3 Auxiliary Input & Output
- 6.4 Door Alarms
- 6.5 Internal Case and Back Tamper
- 6.6 Lockout Feature (Keypad / Card Tamper)
- 6.7 Request to Exit (REX) Function
- 6.8 Secure Application Appurtenances
- 6.9 Programming the AYC- F/G/M60
- Programming Menu
- Entering Programming Mode
- Exiting Programming Mode
- Changing Lock Strike Code
- Changing Auxiliary Code
- Changing the Programming Code
- Changing the Normal / Secure Code
- Changing the Normal / Bypass Code and Door Chime Settings
- Setting Fail Safe/Secure Operation, Tamper Siren and Lock Strike Release Time
- Defining the Auxiliary Input and Output
- Quick Reference Guide for Auxiliary Mode Setting
- Detailed Reference Guide
- Setting the Lockout Feature
- Setting the backlight behavior
- Enrolling Primary and Secondary Codes
- Deleting Primary and Secondary Codes
- Relay Codes Assignment
- Relay Code Assignment using Search Method
- Pin Code Length / Factory Default Settings
- Replacing a Lost Programming Code
- Replacing a Lost Normal / Secure Code
AYC-Qx4 family manual Page 8
Specifications AYC- F/G/M60
Environmental Characteristics
Operating temp. range
-22 to 150° F (-30 to 65° C)
Operating humidity
0 – 95% (non-condensing)
Outdoor usage
Weather-resistant, meets IP-65, epoxy
potted, suitable for outdoor use
Mechanical
Size
(Height x Width x Depth)
F: 4.72 x 3 x 0.827 inches (120 x 76 x 21 mm)
G: 5.39 x 1.73 x 0.83 inches (137 x 44 x21 mm)
M: XXXXXXXXX (XXXXXX)
Weight
F: 1.05 lb (480g) G: 0.35 lb (160g)
M: XXXXXX
*Measured using Rosslare proximity card (AT-14) or equivalent.
Range also depends on electrical environment and proximity to
metal.
2.1 Key Features
The key features for the AYC- F/G/M60 series are:
• Built-In Proximity Card Reader (125 KHz ASK/FSK
Modulation) (for 60 series only)
• Patented, programmable Blue backlit keypad
• Optical back tamper sensor and open controller tamper
output.
• Lockout feature on wrong entry (Keypad / Card Tamper)
• Internal buzzer provides audible interface feedback
• Two status / programming Interface LEDs (tri-colored)
• Fully potted construction for outdoor use
• Comes with mounting template for easier installation
• Comes with an installation kit that includes a security
screw and a security screw tool
