Deleting Primary and Secondary Codes
There are two methods to delete Primary and Secondary codes:
the Standard Method and the Code Search Method.
When deleting a User Slot, both the Primary Code and the
Secondary code are erased.
Deleting Primary and Secondary Codes using the Standard
Method
1) Enter the Programming
Mode.
Mode/Transmit
Door/Program
Green
8
2) Press 8 to enter Menu 8.
• The Door LED will turn
orange
Mode/Transmit
Door/Program
Red Oran
g
e
• The Mode LED will turn
red
3) Enter the 3-digit User Slot code you
wish to delete.
???
• The Mode LED will flash
red Indicating the
controller is waiting for
the Programming Code to confirm the deletion.
If the User Slot is empty, you will hear a long beep and the
AYC- F/G/M60 will return to Normal Mode.
Mode/Transmit
Door/Program
Red
Orange
4) Enter your programming code to
confirm the deletion.
If the programming code is valid, three beeps will be heard
and the controller will return to its normal mode.
If the programming code is invalid, a long beep will be heard
and the controller will return to its normal mode.
? ? ? ?
Note:
• It is recommended that a record be kept of added and
deleted users so that it will be easier to keep track of
which user slots are empty and which user slots are not.
