Enrolling Secondary Codes using the Code Search Method
The Code Search feature enables you to quickly enroll a
Secondary Code to a user who already has a Primary Code.
1) Enter the Programming
Mode.
Mode/Transmit
Door/Program
Green
7
2) Press 7 to enter Menu 7.
• The Door LED will turn
orange
Mode/Transmit
Door/Program
Oran
g
e
3) Enter 000 as the 3-digit User Slot
number.
000
• The Door LED will flash
orange.
Mode/Transmit
Door/Program
Orange
The controller is now waiting for the Primary Code of the User to
whom you want to add a Secondary Code.
4) Enter the Primary Code belonging to the user for whom you
wish to add a Secondary C
• The M
ode.
ode LED will flash
ary Code entered is not valid, you will hear a long beep
ter the Code to be used as the Secondary Code.
eep
roller will sound a
Mode/Transmit
Door/Program
Red
Orange
red.
If the Prim
and the AYC- F/G/M60 will continue to wait for a valid Primary
Code.
5) En
• If the Secondary Code is valid, the controller will b
three times and return to Normal Mode.
• If the Secondary Code is invalid the cont
long beep, and the AYC- F/G/M60 will continue to wait for
a valid Secondary Code to be entered.
