User's Manual
Table Of Contents
- 1. General Information
- 2. Technical Specifications
- 3. Installation
- 4. Wiring Instructions
- 5. Reader Functionality
- 5.1 Transmit Mode
- 5.2 Programming the AYC- F/G/M60 Series
- Programming Menu
- Entering Programming Mode
- Exiting Programming Mode
- Selecting Keypad Transmission Format
- Keypad Transmission Format Option Number
- Option 1: Single Key, 6-Bit Wiegand (Rosslare Format)
- Option 2: Single Key, 6-Bit Wiegand Nibble and Parities
- Option 3: Single Key, 8-Bit Wiegand Nibbles Complemented
- Option 4: 4 Keys Binary + Facility Code, 26-Bit Wiegand
- Option 5: 1 to 5 Keys + Facility Code, 26-Bit Wiegand
- Option 6: 6 Keys BCD and parity bits, 26-Bit Wiegand
- Option 7: Single Key, 3x4 Matrix Keypad (MD-P64)
- Option 8: 1 to 8 Keys BCD, Clock & Data
- Option 9: Single Key, 4-bit Wiegand
- Selecting Proximity Card Transmission Format
- Changing the Programming Code
- Changing the Facility Code
- Setting the Backlight and Reader Format
- Return to Factory Default Settings
- Replacing a Lost Programming Code
- 6. Controller Functionality
- 6.1 Normal, Secure, and Master Users
- 6.2 Modes of Operation
- 6.3 Auxiliary Input & Output
- 6.4 Door Alarms
- 6.5 Internal Case and Back Tamper
- 6.6 Lockout Feature (Keypad / Card Tamper)
- 6.7 Request to Exit (REX) Function
- 6.8 Secure Application Appurtenances
- 6.9 Programming the AYC- F/G/M60
- Programming Menu
- Entering Programming Mode
- Exiting Programming Mode
- Changing Lock Strike Code
- Changing Auxiliary Code
- Changing the Programming Code
- Changing the Normal / Secure Code
- Changing the Normal / Bypass Code and Door Chime Settings
- Setting Fail Safe/Secure Operation, Tamper Siren and Lock Strike Release Time
- Defining the Auxiliary Input and Output
- Quick Reference Guide for Auxiliary Mode Setting
- Detailed Reference Guide
- Setting the Lockout Feature
- Setting the backlight behavior
- Enrolling Primary and Secondary Codes
- Deleting Primary and Secondary Codes
- Relay Codes Assignment
- Relay Code Assignment using Search Method
- Pin Code Length / Factory Default Settings
- Replacing a Lost Programming Code
- Replacing a Lost Normal / Secure Code
AYC-Qx4 family manual Page 48
Secondary Codes
• Secondary Codes can only be enrolled to User Slot that
already has a Primary Code enrolled but no Secondary
Code.
• Secondary Codes do not have to be unique, i.e. multiple
users can all hold the same Secondary Code.
• Secondary Codes cannot be the same as any system
codes, such as the Normal / Secure Code or Lock Strike
Codes.
• Users who hold Secondary Codes can gain entry in any
Mode of Operation.
Enrolling Primary and Secondary Codes
There are two methods to enroll Primary and Secondary codes,
the Standard Method and the Code Search Method.
• The Standard Method is mainly used when the User Slot
number for the user you wish to program is known. You can
program both Primary and Secondary Codes using the
Standard method. (See Enrolling Primary and Secondary
Codes using the Standard Method on page 48.)
• The Code Search Method is mainly used when enrolling a
user’s Secondary Code and the User Slot Code is
unknown.
The Code Search method only works if a user’s Primary Code is
already enrolled but the Secondary Code is not. (See Enrolling
Secondary Codes using the Code Search Method on page 50.)
Enrolling Primary and Secondary Codes using the Standard
Method
