AYC-Qx4 family manual
Page 33
passed. After this time, the door will be locked even if the REX
Button has not been released.
Fail Safe Operation: From the moment the REX Button is pressed,
the door will be unlocked until t
he REX Button is released, plus the
gned for use
trol units,
ide Lock Strike output and
between the AYC- F/G/M60 and the
ties.
he unit's
ach the
ng
/M60
Lock Strike Release Time. In this case the Lock Strike Relay only
begins its count down once the REX Button has been released.
6.8 Secure Application Appurtenances
Rosslares’ secure application appurtenances are desi
with Rosslare's secured series stand alone access con
including AYC- F/G/M60. It is designed to operate indoors and
installed within the secured premises.
The AYC- F/G/M60 must be used with one of Rosslares’ secure
application appurtenances, which prov
Request to Exit (REX) Input.
Both units communicate through a proprietary Rosslare protocol,
which provides a secure link
appurtenances unit. This in turn activates the door lock.
The units also function as the power supply for the AYC- F/G/M60;
it also contains a speaker connection for all sounder abili
For more information see the specific Appurtenances Manual.
6.9 Programming the AYC- F/G/M60
Programming the AYC- F/G/M60 is done solely via t
keypad driven Programming Menu System. To re
Programming Menu System the AYC- F/G/M60 must first be
placed into Programming mode. See Entering Programmi
Mode on page 34 for more information. During the AYC- F/G
's manufacturing process certain codes and settings are pre-
programmed. These settings are the called the Default Factory
Settings. The table below shows the names of all the AYC-
F/G/M60 Menus. It also shows of all the AYC- F/G/M60’s default
factory codes and settings.
