User's Manual
Table Of Contents
- 1. General Information
- 2. Technical Specifications
- 3. Installation
- 4. Wiring Instructions
- 5. Reader Functionality
- 5.1 Transmit Mode
- 5.2 Programming the AYC- F/G/M60 Series
- Programming Menu
- Entering Programming Mode
- Exiting Programming Mode
- Selecting Keypad Transmission Format
- Keypad Transmission Format Option Number
- Option 1: Single Key, 6-Bit Wiegand (Rosslare Format)
- Option 2: Single Key, 6-Bit Wiegand Nibble and Parities
- Option 3: Single Key, 8-Bit Wiegand Nibbles Complemented
- Option 4: 4 Keys Binary + Facility Code, 26-Bit Wiegand
- Option 5: 1 to 5 Keys + Facility Code, 26-Bit Wiegand
- Option 6: 6 Keys BCD and parity bits, 26-Bit Wiegand
- Option 7: Single Key, 3x4 Matrix Keypad (MD-P64)
- Option 8: 1 to 8 Keys BCD, Clock & Data
- Option 9: Single Key, 4-bit Wiegand
- Selecting Proximity Card Transmission Format
- Changing the Programming Code
- Changing the Facility Code
- Setting the Backlight and Reader Format
- Return to Factory Default Settings
- Replacing a Lost Programming Code
- 6. Controller Functionality
- 6.1 Normal, Secure, and Master Users
- 6.2 Modes of Operation
- 6.3 Auxiliary Input & Output
- 6.4 Door Alarms
- 6.5 Internal Case and Back Tamper
- 6.6 Lockout Feature (Keypad / Card Tamper)
- 6.7 Request to Exit (REX) Function
- 6.8 Secure Application Appurtenances
- 6.9 Programming the AYC- F/G/M60
- Programming Menu
- Entering Programming Mode
- Exiting Programming Mode
- Changing Lock Strike Code
- Changing Auxiliary Code
- Changing the Programming Code
- Changing the Normal / Secure Code
- Changing the Normal / Bypass Code and Door Chime Settings
- Setting Fail Safe/Secure Operation, Tamper Siren and Lock Strike Release Time
- Defining the Auxiliary Input and Output
- Quick Reference Guide for Auxiliary Mode Setting
- Detailed Reference Guide
- Setting the Lockout Feature
- Setting the backlight behavior
- Enrolling Primary and Secondary Codes
- Deleting Primary and Secondary Codes
- Relay Codes Assignment
- Relay Code Assignment using Search Method
- Pin Code Length / Factory Default Settings
- Replacing a Lost Programming Code
- Replacing a Lost Normal / Secure Code

AYC-Qx4 family manual Page 28
6. Controller Functionality
The AYC- F/G/M60 series can function both as a reader and as a
controller. If the unit is connected to Rosslares’ secure application
appurtenance, it functions as a controller indicated by two beeps
immediately after power-on reset.
The lock strike output and Request to Exit input are not located on
the AYC- F/G/M60 unit, eliminating the possibility of unauthorized
entry to the restricted area.
The following explains how the AYC- F/G/M60 series functions as a
controller.
6.1 Normal, Secure, and Master Users
The AYC- F/G/M60 accepts up to 500 users and provides entry via
the use of PIN codes and/or Proximity cards. Each user is provided
with two code memory slots, Memory Slot 1 (Primary Code) and
Memory Slot 2 (Secondary Code).
The pin code length has several options. The pin code length can
be a set number of 4, 5 or 6 digits or it can be a 4-8 digits option.
When choosing the 4-8 digit option, please note that you should
either enter zeros before the code, or press pound at the end (for
example if your code is 12345, enter either 00012345 or 12345#).
Note:
• Entering a code refers to either PIN or CARD depending
on the model you have.
The way in which the two memory slots are programmed
determines a user’s access level and also determines the way in
which the AYC- F/G/M60 grants access in its three modes of
operation. There are three user levels:
Normal User
A Normal User only has a Primary Code and is only granted
access when the AYC- F/G/M60 is in Normal or Bypass Mode.
