Entering Programming Mode
1) Press the # key 4 times.
• Transmit LED will turn off.
Mode/Transmit
Door/Program
Red
• Program LED will turn red.
2) Enter your 4 digit Programming
Code. If the Programming Code is
valid, the door LED will turn
green and the AYC-
F/G/M60 will be in Programming Mode.
? ? ? ?
Door/Program
Mode/Transmit
Green
Note:
• The factory 4-digit Programming Code is 1234.
• If a Programming Code is not entered within 30 seconds,
the AYC- F/G/M60 will return to Transmit Mode.
Exiting Programming Mode
1) To exit the Programming Mode at any time press #:
• You will hear a beep
Mode/Transmit
AYC-Qx4 family manual Page 16
Door/Program
Red
• The Program LED will be
off
• The Transmit LED will turn red
2) This indicates that the AYC- F/G/M60 has returned to Transmit
Mode.
3) Wrong entries may reset the reader back to Transmit Mode.
While in Programming Mode if no key is pressed for 30
seconds the AYC- F/G/M60 will exit Programming Mode and
return to Transmit Mode.
Selecting Keypad Transmission Format
The AYC- F/G/M60 has eight different keypad transmission formats
to select from. Follow the steps below to select the appropriate
keypad transmission format that you wish to use.
1) Enter Programming Mode.
Green
Door/Program
Mode/Transmit
