User's Manual

Page 3
06/04
Introduction
Equipment provided
The following is provided as part of every AYC-G64 package:
The AYC-G64 is a waterproof programmable Wiegand and Clock &
Data proximity card and keypad reader. The AYC-G64 supports
multiple Proximity Card and Keypad formats providing a high level
of compatibility and connectivity with host controllers.
The unit can be programmed to output proximity card data in 26-Bit
Wiegand, Clock & Data or Wiegand Card + PIN format.
The backlit keypad can also be programmed to output eight
different data formats.
The AYC-G64 utilizes flash firmware for easy upgrades.
- AYC-G64 Access Control Unit.
- Installation Kit
- Installation and Operating Instructions
Additional Equipment Required
1) Compatible Host Controller
2) Power Supply
5 to 16V DC (From a Regulated Power Supply)
Other Rosslare accessories can be found at Rosslare's
Web Site:
http://www.rosslaresecurity.com
AYC-G64
Page 2
06/04
Contents
INTRODUCTION 3
Technical Specifications 4
Key Features 5
INSTALLATION 6
Mounting the AYC-G64 reader 6
Wiring the AYC-G64 reader 7
FEATURES AND CONCEPTS
Transmit Mode 8
PROGRAMMING THE AYC-G64 9
Entering Programming Mode 10
Exiting Programming Mode Operation 10
1 Setting Keypad Transmission Format 11
2 Setting Proximity Card Transmission Format 17
3 Changing the Programming Code 19
4 Changing the Facility Codes 20
0 Return to Factory Default Settings 20
Replacing a lost Programming Code 21
WARRANTY 22
TECHNICAL SUPPORT 24
AYC-G64
