IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 User Manual IDE 3-in-1 (5.25”, 3.5”, 2.5”)to USB 2.0 Cable Converter Adapter Included in the Kit The USB to IDE Cable Adapter Complete Kit includes the items listed below. 1. USB to IDE Cable Adapter The Cable Adapter is powered from USB bus. It can connect to two different types of drive mechanisms. IDE Drives connect through the 2.5” connector or the 3.5”, 5.25” connector. 2.
IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 User Manual drive will automatically mount itself. That being said, this is not true for all Operating Systems and a good knowledge of how your OS works is needed. In some systems a drive utility is needed to format or partition the mechanism and or mount the drive. New Mechanisms all need to go through the format and partition routine in order to be used. Also note that drives from different computers, i.e.
IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 User Manual Using the Power Supply The IDE Drive Power connector plugs into any standard IDE, ATAPI, ATA, or SCSI type of drive mechanism. Power should only be supplied to the Drive Mechanism after the Data Cable has been connected to the Cable Adapter. Formatting & Partitioning Drives Formatting & Partitioning After the Cable Adapter and drivers have been plugged in the next step is to format and partition your drive mechanism.
IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 User Manual Package Contents RCW-607 X 1 User manual X 1 Power cord X 1 Power adapter X 1 Driver disc X 1 Silicon protection case for 2.5” hard drive X 1 Silicon protection case for 3.5” hard drive X 1 Installation 1. Plug the 2.5” or 3.5” ATA/ ATAPI device to RCW-607 by IDE interface. (Please notice the direction of IDE port) Please check a to d as below. 3.5" 5.25" 2.
IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 User Manual c. 5.25" ATAPI device ATAPI device 2. Connect the power adapter set. 3. Plug the power adapter to your ATA/ATAPI device. Please check a to d as below. a. 3.
IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 b. 2.5" ATA There is no additional power needed for 2.5” hard drive. c. 5.25" ATAPI 4.
IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 User Manual 5. Plug the USB2.0 cable to PC and wait for PC auto-detection. Driver is needed only in old system such as Windows 98. Please inset the driver disk when your system can’t complete the installation process. Windows will auto-install after it detects the driver disk and choose the most suitable driver for your system. (Please notice the direction of USB port) Notification 1.
IDE 3-in-1 (5.25”,3.5”,2.5”)to USB 2.0 Cable Converter Adapter RCW607 User Manual *Solution: Please contact our RMA department for replacement. ii. Q: After I installed RCW-607 to the hard drive, my hard drive will not run. A: Four pin power connector is directional. If you plug in the four pin power connector in reverse, your hard drive might be damaged. *Solution: Please make sure the direction of 4 pin power connector is correct before you plug it to your hard drive.
