1. Overview
Hardware Control-© 2002 Ronan Engineering 4
1.4.3 Temperature Range
§ Operating – 0° to 60° C (32° to 140° F)
§ Storage - -40° to +85° C (-40° to + 185° F)
1.4.4 Inputs
§ Contact – Dry or Live; Normally Open / Normally Closed
§ Field Selectable
§ Interrogation Voltage – 24 Vdc, 48 Vdc, 125 Vdc, 115 Vac, or 240
Vac
1.4.5 Response Time
§ 20 Milliseconds by default. It can be modified using the X11CA
Configuration software.
1.4.6 EMI/RFI Compatibility
§ CE Compliant
1.4.7 Outputs
§ Visual – Fast Flash, Slow Flash, Steady ON, Intermittent Fast Flash
§ Audible – Dual, Selectable by Cabinet Module
§ Auxiliary Relays – Form C, Selectable Form A or B; Normally not
Energized or Normally Energized
§ Contact Rating – General Purpose: 1 Amps @ 28 Vdc; 0.65 Amp @
115 Vac
§ Common System Trouble – Form C, 2 Amps @ 28 Vdc; 0.65 Amp @
115 Vac – Open Collector Transistor Output 200 mA @ 28 Vac
§ Common System Reflash – Form C, 2 Amps @ 28 Vdc; 0.65 Amp @
115 Vac – Open Collector Transistor Output 200 mA @ 28 Vac
1.4.8 Controls
§ Momentary Push Button: Integral or Remote; Single Pole
§ Normally Open; +V Switched; Silence; Acknowledge; Reset, Test,
GP1, GP2
1.4.9 Diagnostic
§ System Trouble Alarm (RUN) – Form C, 2 Amps @ 28 Vdc; 0.65
Amp @ 115 Vac
§ System Trouble Alarm (RUN) – Indicating LED Green
§ Communication Diagnostic (ERROR) – Indicating LED Red
§ Transmit/Receiver LED Pair
