5. Appendix B: Data Conversion (Bin to Dec) Table
Hardware Control-© 2002 Ronan Engineering 45
SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Binary Address
Decimal
Equivalent
ON ON OFF OFF OFF OFF ON ON 1100 0011 195
ON ON OFF OFF OFF ON OFF OFF 1100 0100 196
ON ON OFF OFF OFF ON OFF ON 1100 0101 197
ON ON OFF OFF OFF ON ON OFF 1100 0110 198
ON ON OFF OFF OFF ON ON ON 1100 0111 199
ON ON OFF OFF ON OFF OFF OFF 1100 1000 200
ON ON OFF OFF ON OFF OFF 0N 1100 1001 201
ON ON OFF OFF ON OFF ON OFF 1100 1010 202
ON ON OFF OFF ON OFF ON ON 1100 1011 203
ON ON OFF OFF ON ON OFF OFF 1100 1100 204
ON ON OFF OFF ON ON OFF ON 1100 1101 205
ON ON OFF OFF ON ON ON OFF 1100 1110 206
ON ON OFF OFF ON ON ON ON 1100 1111 207
ON ON OFF ON OFF OFF OFF OFF 1101 0000 208
ON ON OFF ON OFF OFF OFF ON 1101 0001 209
ON ON OFF ON OFF OFF ON OFF 1101 0010 210
ON ON OFF ON OFF OFF ON ON 11101 0011 211
ON ON OFF ON OFF ON OFF OFF 11101 0100 212
ON ON OFF ON OFF ON OFF ON 11101 0101 213
ON ON OFF ON OFF ON ON OFF 11101 0110 214
ON ON OFF ON OFF ON ON ON 11101 0111 215
ON ON OFF ON ON OFF OFF OFF 11101 1000 216
ON ON OFF ON ON OFF OFF 0N 11101 1001 217
ON ON OFF ON ON OFF ON OFF 11101 1010 218
ON ON OFF ON ON OFF ON ON 11101 1011 219
ON ON OFF ON ON ON OFF OFF 11101 1100 220
ON ON OFF ON ON ON OFF ON 11101 1101 221
ON ON OFF ON ON ON ON OFF 11101 1110 222
ON ON OFF ON ON ON ON ON 11101 1111 223
ON ON ON OFF OFF OFF OFF OFF 11110 0000 224
ON ON ON OFF OFF OFF OFF ON 11110 0001 225
ON ON ON OFF OFF OFF ON OFF 11110 0010 226
ON ON ON OFF OFF OFF ON ON 11110 0011 227
ON ON ON OFF OFF ON OFF OFF 11110 0100 228
ON ON ON OFF OFF ON OFF ON 11110 0101 229
ON ON ON OFF OFF ON ON OFF 11110 0110 230
ON ON ON OFF OFF ON ON ON 11110 0111 231
ON ON ON OFF ON OFF OFF OFF 11110 1000 232
ON ON ON OFF ON OFF OFF 0N 11110 1001 233
ON ON ON OFF ON OFF ON OFF 11110 1010 234
ON ON ON OFF ON OFF ON ON 11110 1011 235
