ROHO® SOFFLEX® 2 Mattress Replacement System Operation Manual SUPPLIER: This manual must be kept with this product. CAREGIVER: Before using this product, read these instructions and save for future reference.
TABLE OF CONTENTS WARNINGS AND CAUTIONS 2-3 INTENDED USE 3 PRODUCT SPECIFICATIONS 3 PARTS DETAIL 4 ADJUSTMENT INSTRUCTIONS 5-6 LINENS 7 TROUBLESHOOTING 7 CONTACT INFORMATION 7 CLEANING AND DISINFECTING 8 DISPOSAL 9 RETURN POLICY 9 LIMITED WARRANTY 9 ROHO, Inc. has a policy of continual product improvement and reserves the right to amend this document. The current version of this document is available at www.roho.com. ROHO, Inc.
WARNINGS Mattress - Entrapment and Fall Risks: Medical experts and governmental entities in various countries have determined that the use of side rails on beds may present a life-threatening entrapment danger to the individual. Bed frame side rail usage is not a requirement for the functional operation of any ROHO product; however, the use of side rails may be clinically indicated for certain individuals.
CAUTIONS • Changes in altitude may require adjustment to your product. • Keep the product away from sharp objects, which may puncture the air cells and cause deflation. • DO NOT expose the product to high heat, open flames or hot ashes. • If a product has been in temperatures less than 32°F / 0°C and exhibits unusual stiffness, allow the product to warm to room temperature. • The use of any inflation device other than those supplied by ROHO may damage the product and void the warranty.
PARTS DETAIL Package Contents: Mattress Cover Top Air Cell Pads Inner Liner Bolsters (Models > 36 in. / 91.5 cm wide) Foam Base Tubing Mattress Cover Bottom Inflation Port Tabs Inflation Port ROHO® SOFFLEX® 2 Mattress Replacement System Deflation Adapters Operation Manual Inflation Port Valves SUPPLIER: This manual must be kept with this product. CAREGIVER: Before using this product, read these instructions and save for future reference.
ADJUSTMENT INSTRUCTIONS The SOFFLEX 2 Mattress MUST be used with the provided cover. (For demonstration purposes only, top of cover may not be shown.) 1. Place SOFFLEX 2 Mattress directly on the bed frame. 2. Secure the SOFFLEX 2 Mattress to the bed frame using the straps on the bottom of the cover. 3. Insert the Quick Connect on the manual Hand Pump into an Inflation Port Valve until a click is heard.
ADJUSTMENT INSTRUCTIONS, Continued 6. While the SOFFLEX 2 Mattress is still unloaded, insert a Deflation Adapter into each Inflation Port Valve and allow air to bleed out of each section until the internal air pressure reaches atmospheric pressure. Note: You will know when the atmospheric adjustment is completed when no additional air is escaping from the Inflation Valve Port. This will take approximately five (5) minutes.
LINENS Too many linens between the product and the individual will compromise the product’s skin protection characteristics. Please use as few linens and incontinent pads as possible. TROUBLESHOOTING If the product does not appear to be maintaining adjustment, reinflate, and redo the adjustment procedure. If concern persists, contact your service provider, clinical caregiver, distributor, or ROHO, Inc. immediately. CONTACT INFORMATION In the U.S.
CLEANING AND DISINFECTING Cleaning and disinfecting are two separate processes. Cleaning must precede disinfection. Note: SOFFLEX 2 Mattress must be cleaned, disinfected and checked for proper functioning between use by different individuals. WARNINGS PRIOR TO CLEANING AND DISINFECTING: Remove linens. Examine the cover to be sure that it has NOT been damaged in such a way to cause internal parts to come in contact with bodily fluids, e.g., punctured, torn, worn area.
DISPOSAL When properly used and disposed of, the components of the products in this manual are associated with no known environmental hazards. Dispose of the product and/or components in accordance with the applicable regulations in your jurisdiction. DO NOT INCINERATE. RETURN POLICY All products returned must be new and unused, require prior authorization from ROHO, Inc., and are subject to a restocking charge. Before returning a product: In the U.S.A.
Item #: T20225 Revision: 08/04/14 Mailing/Shipping Address: 1501 South 74th Street, Belleville, IL 62223-5900, USA Administrative Offices: 100 North Florida Avenue, Belleville, IL 62221-5429, USA U.S.: 800-851-3449 • Fax 888-551-3449 Outside U.S.: 618-277-9150 • Fax 618-277-6518 www.roho.
