Data Sheet
EMH4 / UMH4N / IMH4A
lDimensions (Unit : mm)
Dimension in mm/inches
EMT6
Patterm of terminal position areas
b
D
e
Lp
Lp
E
H
E
LL
x S A
A
c
A1
A
y
S
S
e1
b2
l1
e
MIN MAX MIN MAX
A1 0.00 0.10 0 0.004
A 0.45 0.55 0.018 0.022
b 0.17 0.27 0.007 0.011
c 0.08 0.18 0.003 0.007
D 1.50 1.70 0.059 0.067
E 1.10 1.30 0.043 0.051
e
HE 1.50 1.70 0.059 0.067
L 0.10 0.30 0.004 0.012
Lp - 0.35 - 0.014
x - 0.10 - 0.004
y - 0.10 - 0.004
MIN MAX MIN MAX
e1
b2 - 0.37 - 0.015
l1 - 0.45 - 0.018
INCHES
0.50
0.02
DIM
MILIMETERS
MILIMETERS
INCHES
1.25
0.049
DIM
4/6
