STATus:OPERation:INSTrument:NTRansition <NegativePosition>
STATus:OPERation:INSTrument:ISUMmary<Channel>:NTRansition <arg0>
Sets/Queries the negative transition filter. Setting a bit in the negative transition filter
shall cause a 1 to 0 transition in the corresponding bit of the associated condition regis-
ter to cause a 1 to be written in the associated bit of the corresponding event register.
Suffix:
<Channel>
.
1..n
Parameters:
<NegativeTransition> Range: <1 to 65535>
Example:
STATus:OPERation:INSTrument:ISUMmary1:
NTRansition?
Query for negative transition.
STATus:OPERation:INSTrument:PTRansition <PositiveTransition>
STATus:OPERation:INSTrument:ISUMmary<Channel>:PTRansition <arg0>
Sets/Queries the positive transition filter. Setting a bit in the positive transition filter
shall cause a 0 to 1 transition in the corresponding bit of the associated condition regis-
ter to cause a 1 to be written in the associated bit of the corresponding event register.
Suffix:
<Channel>
.
1..n
Parameters:
<PositiveTransition> Range: <1 to 65535>
Example:
STATus:OPERation:INSTrument:ISUMmary1:
PTRansition?
Query for positive transition.
7.10.2 STATus:QUEStionable Registers
The commands of the STATus:QUEStionable subsystem control the status reporting
structures of the STATus:QUEStionable registers:
The suffix <n> at Channel selects the instrument. The range is <1...2>.
●
Chapter A.3.1, "Structure of a SCPI Status Register", on page 138
●
STATus:QUEStionable Register
STATus:QUEStionable:INSTrument:CONDition?............................................................... 130
STATus:QUEStionable:INSTrument:ISUMmary<Channel>:CONDition?............................... 130
STATus:QUEStionable:INSTrument:ENABle..................................................................... 130
STATus:QUEStionable:INSTrument:ISUMmary<Channel>:ENABle..................................... 130
STATus:QUEStionable:INSTrument[:EVENt]?................................................................... 130
STATus:QUEStionable:INSTrument:ISUMmary<Channel>[:EVENt]?................................... 130
STATus:QUEStionable:INSTrument:NTRansition...............................................................131
STATus:QUEStionable:INSTrument:ISUMmary<Channel>:NTRansition...............................131
