Usage: Setting only
ARBitrary:TRIGgered:MODE <mode>
ARBitrary:TRIGgered:MODE?
Sets/Queries the arbitrary trigger mode of the previous selected channel.
Parameters:
<mode> SINGle | RUN
SINGle
A trigger event starts only one arbitrary sequence.
RUN
A trigger event starts the whole arbitrary sequence (with all repi-
titions).
ARBitrary:TRIGgered[:STATe] <state>
ARBitrary:TRIGgered[:STATe]?
Activates/Deactivates or Queries the trigger input at the rear connector (terminal block)
for arbitrary functionality..
Parameters:
<state> 0 | 1
0
OFF - Trigger input is deactivated.
1
ON - Trigger input is activated.
Example:
INST OUT1
ARB:TRIG ON
ARB:TRIG? -> 1
Trigger input on the rear connector is activated for Ch1 arbitrary
waveform
7.8 Advanced Operating Commands
The VOLTage:RAMP and Sequencing subsystem contains the commands for config-
uring the ramp function and sequencing function for the output channels.
7.8.1 Ramp
[SOURce:]VOLTage:RAMP[:STATe]..................................................................................119
[SOURce:]VOLTage:RAMP:DURation...............................................................................119
