ARBitrary:DATA <data>
ARBitrary:DATA?
Sets/Queries the arbitrary points for the previous selected channel. Max. 512 arbitrary
points can be defined. The dwell time between 2 arbitrary points is specified from 10
ms to 10 minutes.
Parameters:
<data> voltage1, current1, time1, interpolation mode1, voltage2, cur-
rent2, time2, interpolation mode2, ...
Voltage and current setting depending on the instrument type.
The interpolation mode if sets 1 indcates that interpolation mode
is activated and if sets 0, indcates that interpolation mode is dis-
abled.
Example:
INST OUT1
ARB:DATA 10,1,0.5,0
Defines one arbitrary point with: Voltage1 = 10 V and Current1 =
1 A, Time1 = 500 ms and Interpolation mode1 = 0 (disabled).
ARB:DATA -> 10.000, 1.000, 0.50, 1
Return defined arbitrary points for the previous selected chan-
nel.
See Example "Configuring an arbitrary sequence" on page 114.
ARBitrary:ENDPoint <endpoint>
ARBitrary:ENDPoint?
Queries the defined arbitrary waveform endpoint of the selected channel.
Parameters:
<endpoint> Range: 0 to 512
Example:
INST OUT1
ARB:ENDP 30
ARB:ENDP? -> 30
The the arbitrary waveform of channel Ch1 will be repeated 30
times
ARBitrary:FNAMe <filename>[,<location>]
ARBitrary:FNAMe? [<location>]
Sets/Queries the file name and storage location for the arbitrary function.
Parameters for setting and query:
<filename> Filename of the arbitrary function.
<location> INT | EXT | DEF
INT
Internal memory
EXT
USB stick
