7.6 Measurement Commands
The MEASure subsystem provides commands to query the voltage and current values
of a channel.
MEASure[:SCALar]:CURRent[:DC]?.................................................................................112
MEASure[:SCALar]:ENERgy?......................................................................................... 112
MEASure[:SCALar]:ENERgy:RESet................................................................................. 112
MEASure[:SCALar]:ENERgy:STATe................................................................................. 112
MEASure[:SCALar]:POWer?........................................................................................... 113
MEASure[:SCALar][:VOLTage][:DC]?............................................................................... 113
MEASure[:SCALar]:CURRent[:DC]?
Queries the currently measured current of the selected channel.
Example:
MEAS:CURR? -> 1.000E +00
Usage: Query only
MEASure[:SCALar]:ENERgy?
Queries the measured the current released energy value of the previous selected
channel. Please notice that the energy meter has to be activated to measure the cur-
rent released energy value.
Example:
MEAS:ENER? -> 5.382E+00 (value in Wh)
Usage: Query only
MEASure[:SCALar]:ENERgy:RESet
Resets the energy counter for the selected channel.
Usage:
Event
MEASure[:SCALar]:ENERgy:STATe <state>
MEASure[:SCALar]:ENERgy:STATe?
Activates/Deactivates or Queries the energy counter for the selected channel.
Parameters:
<state> OFF | ON | 0 | 1
ON |1
Activates the energy counter.
OFF | 0
Deactivates the energy counter.
