Instruction Manual

Kinetix VP Low-inertia Servo Motor with 063…165 mm Frame Size 29
Rockwell Automation Publication VPL-IN001C-EN-P - November 2013
Shaft Seal Kits
Shaft seals are subject to wear and require periodic inspection and replacement. Replacement is
recommended every 3 months, not to exceed 12 months, depending on use.
Catalog numbers and dimensions for Nitrile shaft seal kits are shown below.
Additional Resources
These documents contain information concerning related products from Rockwell Automation.
You can view or download publications at http://www.rockwellautomation.com/literature
. To
order paper copies of technical documentation, contact your local Allen-Bradley distributor or
Rockwell Automation sales representative.
Motor Cat. No. Shaft Seal Kit Cat. No. Inside Diameter Outside Diameter Width
mm (in.) mm (in.) mm (in.)
VPL-A063xx and VPL-B063xx
VPL-SSN-F063075 12 (0.47) 28 (1.10)
7 (0.28)
VPL-A075xx and VPL-B075xx
VPL-A100xx and VPL-B100xx VPL-SSN-A3B3 17 (0.67) 47 (1.85)
VPL-A115xx and VPL-B115xx MPL-SSN-A4B4 20 (0.79) 52 (2.05)
VPL-A130xx and VPL-B130xx MPL-SSN-A5B5 25 (0.98) 62 (2.44)
VPL-B165xx MPL-SSN-F165 30 (1.18) 72 (2.83) 8 (0.31)
IMPORTANT
Nitrile shaft seals require a lubricant to reduce wear. Lubricant is supplied with the kit.
Resource Description
Kinetix 5500 Servo Drives User Manual, publication
2198-UM001
Information on installing, configuring, starting up, and
troubleshooting a servo drive system.
Kinetix 5500 Drive System Design Guide, publication
GMC-RM009
Information on drive system components and accessory items you
need for your Kinetix 5500 drive/motor combination.
Shaft-seal Kit Installation Instructions, publication
2090-IN012
Information on the installation of a shaft seal on this and other servo
motors.
Kinetix Rotary Motion Specifications Technical Data,
publication GMC-TD001
Product specifications for Allen-Bradley® rotary motors, with
performance, environmental, certifications, load force, and
dimension drawings.
Kinetix Motion Accessories Specifications, publication
GMC-TD004
Product specifications and dimensions for Allen-Bradley servo drive
accessories.
Allen-Bradley Industrial Automation Glossary, publication
AG-7.1
A glossary of industrial automation terms and abbreviations.
System Design for Control of Electrical Noise Reference
Manual, publication GMC-RM001
Information, examples, and techniques designed to minimize system
failures caused by electrical noise.
