Instruction Manual

28 Kinetix VP Low-inertia Servo Motor with 063…165 mm Frame Size
Rockwell Automation Publication VPL-IN001C-EN-P - November 2013
Environmental Ratings
2090-Series Single Motor Cables
Factory-manufactured single motor cables are required with Kinetix VP low-inertia motors.
Single motor cables are designed to effectively isolate the power, and feedback or brake signals,
within the cable. Single motor cables are available in standard cable lengths, and provide
environmental and shield termination.
Contact your nearest Rockwell Automation sales office or refer to the Kinetix Motion
Accessories Technical Data, publication GMC-TD004
, for information about available
2090-Series single motor cables.
Attribute Value
Temperature, operating 0…40 °C (32…104 °F)
(3)
(3) To obtain this thermal rating, mount the motor on a surface with heat dissipation equivalent to the size of an aluminum heatsink as listed here:
frame 063 mm, 203.2 x 203.2 x 6.35 mm (8 x 8 x 0.25 in.);
frame 075 mm, 254.0 x 254.0 x 6.35 mm (10 x 10 x 0.25 in.);
frames 100…165 mm, 304.8 x 304.8 x 12.7 mm (12 x 12 x 0.5 in.).
Temperature, storage -30…40 °C (-22…104 °F)
Relative humidity, storage 5…95% noncondensing
Atmosphere, storage Noncorrosive
IP rating
(1)
of motor with optional shaft seal
(2)
and use of
environmentally sealed cable connectors
(1) International Protection Code (IP66) is roughly equivalent to a NEMA 35 (dust tight, drip tight).
(2) An optional shaft seal kit is required to provide the specified IP rating for the motor. A system level rating is also dependent on the IP rating of the
cable. See Additional Resources
on page 29 for information on shaft seal installation instructions.
IP66 – dust tight, jet spray
IP rating of motor without a shaft seal, and mounted in this direction:
• Shaft down
• Shaft horizontal
• Shaft up
• IP53 – dust tight, powerful water jets
• IP51 – dust tight, water dripping vertically
• IP50 – dust tight, no protection from water
