26 Kinetix VP Low-inertia Servo Motor with 063…165 mm Frame Size
Rockwell Automation Publication VPL-IN001C-EN-P - November 2013
Axial Load Force Ratings (maximum radial load) for Brake Motors (kgf)
(1)
(2)
(100…165 mm frame size)
(1) 1 kgf = 9.8 N (2.2 lbf).
(2) An asterisk (*) next to a load rating indicates a load rating measured at an rpm value that is less than the value listed for that column.
Motor Cat. No. RPM
500 750 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000
VPL-A1001C 31.0 –23.0 –17.0 –14.0 *––––––––
VPL-A1001M –––19.0 –15.0 –––12.0 –––10.0–
VPL-A1002C 34.0 –25.0 –18.0 –15.0 ––––––––
VPL-A1002F ––25.0 21.0––15.0 –––12.0 ––––
VPL-A1003C36.0 –26.022.0 –18.0 *–––––––––
VPL-A1003E36.0 –26.0 –19.0 –––15.0 *––––––
VPL-A1003F–––22.0 –18.0 ––14.0 ––12.0 –––
VPL-A1152B50.0 –37.0 31.0 –26.0 *–––––––––
VPL-A1152E51.0–37.0–27.0 ––22.0 *–––––––
VPL-A1152F––37.0 –27.0 –23.0 –––18.0 ––––
VPL-A1153C 53.0 –39.0 32.0 –27.0 *–––––––––
VPL-A1303B46.0 –34.0 28.0 25.0 *––––––––––
VPL-A1303E ––34.0 –25.0–21.0 –18.0 ––––––
VPL-A1304A48.0 40.0 36.0 *–29.0 *––––––––––
VPL-A1304D 48.0 –36.0 –26.0–22.0 ––––––––
VPL-A1306C 52.0 –42.0 *33.3 *28.0 ––––––––––
VPL-B100M ––––17.0–14.0 –12.0 –––10.0 ––
VPL-B1002E 34.0 –25.0 –18.0 ––15.0 *–––––––
VPL-B1002M –––21.0 ––15.0––13.0 ––11.0 ––
VPL-B1003C36.0 –26.0 22.0–18.0–––––––––
VPL-B1003F––26.022.0––16.0 –––13.0 *––––
VPL-B1003T –––22.0 –18.0 –––13.0 ––––11.0
VPL-B1152C 51.0 –37.031.0 –26.0 *–––––––––
VPL-B1152F ––37.0 –27.0 –23.0 ––19.0 –––––
VPL-B1152T –––31.0 –25.0 ––20.0 ––––16.0 –
VPL-B1153E 53.0 –39.0 –29.0 ––23.0*–––––––
VPL-B1153F ––39.0 –29.0 –24.0 –––19.0 ––––
VPL-B1303C 46.0–34.0 28.0–24.0 *–––––––––
VPL-B1303F ––34.0 –25.0 –21.0 *–18.0 ––––––
VPL-B1304C 48.0 –36.0 31.0 *–25.0 *–––––––––
VPL-B1304E ––36.030.0–25.0 *–20.0 –––––––
VPL-B1306C 52.0 –38.0 –31.0 *25.0 –––––––––
VPL-B1306F ––38.0–28.0 –24.0 ––20.0 *–––––
VPL-B1651C 58.0 –43.0 –34.0 *–27.0 *––––––––
VPL-B1651F ––43.0 –31.0 –26.0 –––21.0 *––––
VPL-B1652C64.0 –47.0 39.0 ––30.0 *––––––––
VPL-B1652F––47.640.0–32.0––26.1––––––
VPL-B1653C68.0–50.0 43.0 * –35.0 *–––––––––
VPL-B1653D––50.745.3*39.3*–31.5––––––––
VPL-B1654B71.0 59.0 –50.0 *40.0 *––––––––––
VPL-B1654D––52.944.439.2–32.9––––––––
