Kinetix VP Low-inertia Servo Motor with 063…165 mm Frame Size 23
Rockwell Automation Publication VPL-IN001C-EN-P - November 2013
Axial Load Force Ratings (maximum radial load) for Non-brake Motors (kgf)
(1)
(2)
(100…165 mm frame size)
(1) 1 kgf = 9.8 N (2.2 lbf).
(2) An asterisk (*) next to a load rating indicates a load rating measured at an rpm value that is less than the value listed for that column.
Motor Cat. No. RPM
500 750 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000
VPL-A1001C 25.0 –19.0 –10.0 –10.0 *––––––––
VPL-A1001M –––15.0 –12.0 –––9.0 –––8.0 –
VPL-A1002C 30.0 –22.0 –16.0 –13.0 ––––––––
VPL-A1002F ––22.0 18.0 ––13.0 –––11.0 ––––
VPL-A1003C33.0 –24.0 20.0 –17.0 *–––––––––
VPL-A1003E33.0 –24.0 –18.0 –––13.0 *––––––
VPL-A1003F–––20.0–16.0––13.0––11.0–––
VPL-A1152B44.O –32.0 27.0–23.0 *–––––––––
VPL-A1152E44.0 –32.0 –24.0 ––15.0 *–––––––
VPL-A1152F––32.0 –24.0 –20.0 –––16.0 ––––
VPL-A1153C 48.0 –35.0 29.0 –24.0 *–––––––––
VPL-A1303B39.0 –29.024.022.0 *––––––––––
VPL-A1303E ––29.0 –21.0–18.0–16.0 ––––––
VPL-A1304A43.0 36.032.0 *–26.0 *––––––––––
VPL-A1304D 43.0 –32.0 –23.0 –20.0 ––––––––
VPL-A1306C 48.0 –39.0 *31.0 *26.0 ––––––––––
VPL-B1001M ––––14.0 –11.0 –10.0–––8.0 ––
VPL-B1002E 30.0 –22.0 –16.0 ––13.0 *–––––––
VPL-B1002M –––18.0––13.0 ––11.0––10.0 ––
VPL-B1003C33.0 –24.0 20.0–16.0 –––––––––
VPL-B1003F––24.0 20.0––15.0–––12.0 * ––––
VPL-B1003T –––20.0 –16.0 –––12.0––––10.0
VPL-B1152C 44.0–32.027.0–22.0 *–––––––––
VPL-B1152F ––32.0 –24.0–20.0 ––17.0 –––––
VPL-B1152T –––27.0 –21.0––17.0––––14.0–
VPL-B1153E 48.0 –35.0 –26.0––21.0 * –––––––
VPL-B1153F ––35.0 –26.0–22.0 –––17.0––––
VPL-B1303C 39.0 –29.0–24.020.0 *–––––––––
VPL-B1303F ––29.0–21.0 –18.0 *–16.0 ––––––
VPL-B1304C 43.0–32.0 27.0 *–23.0 *–––––––––
VPL-B1304E ––32.0 27.0 –22.0 *–18.0 –––––––
VPL-B1306C 48.0 –36.0 –29.0 *24.0 –––––––––
VPL-B1306F ––36.0 –26.0–22.0 ––19.0 *–––––
VPL-B1651C 48.0 –35.0 –28.0 *–23.0 *––––––––
VPL-B1651F ––35.0 –26.0 –22.0 –––18.0 *––––
VPL-B1652C58.0–43.0 36.0 ––27.0 * ––––––––
VPL-B1652F––43.136.1–28.9––23.6––––––
VPL-B1653C64.0 –47.0 41.0 *–33.0 *–––––––––
VPL-B1653D––47.642.5*36.9*–29.5––––––––
VPL-B1654B68.0 –57.0 48.0 *38.0 *––––––––––
VPL-B1654D––50.742.537.5–31.5––––––––
