Instruction Manual

Kinetix VP Low-inertia Servo Motor with 063…165 mm Frame Size 19
Rockwell Automation Publication VPL-IN001C-EN-P - November 2013
Radial Load Force Ratings (maximum) for Brake Motors (kgf)
(1) (2)
(063…075 mm frame size)
(1) 1 kgf = 9.8 N (2.2 lbf).
(2) An asterisk (*) next to a load rating indicates a load rating measured at an rpm value that is less than the value listed for that column.
Motor Cat. No. RPM
500 1000 1500 2000 2500 3000 3500 4000 4500 5000 6000 6500 7000 7500 8000
VPL-A0631E –29.2––22.8 *20.3––17.7–––––– VPL-A0631M ––25.5–21.5–––18.3 *––––15.1 *– VPL-A0632F –30.526.6––22.2 *–––18.1 *––––– VPL-A0633C 39.531.428.4 *––21.8––––––––– VPL-A0751E 36.529.0––22.6 *––––17.2 *––––– VPL-A0752C 38.130.327.4–––20.3 *–––––––– VPL-A0752E 38.130.3––23.1 *––––17.9 *––––– VPL-A0753C 39.231.228.5 *–––20.9 *–––––––– VPL-A0753E 39.231.2––24.1 *––––18.7 *––––– VPL-B0631T ––25.5––20.3––––16.4 *–––14.6 VPL-B0631U ––25.5––20.3–––17.1––––14.6 VPL-B0632F –30.526.6––22.2 *–––18.1 *––––– VPL-B0632T –––24.2–––19.2–––16.5 *––15.3 VPL-B0633F –31.427.4–23.1––––18.5 *––––– VPL-B0633M –31.4–24.9–––19.9 *––––16.5 *–– VPL-B0633T ––27.4––21.8––––17.5 *–––15.7 VPL-B0751M ––25.3––20.1–––17.2 *––––14.5
