Axial Load Force Ratings (maximum radial load) for Non-brake Motors (kgf)
(1) (2)
(063…075 mm frame size)
(1) 1 kgf = 9.8 N (2.2 lbf).
(2) An asterisk (*) next to a load rating indicates a load rating measured at an rpm value that is less than the value listed for that column.
Motor Cat. No. RPM
500 1000 1500 2000 2500 3000 3500 4000 4500 5000 6000 6500 7000 7500 8000
VPL-A0631E –22.3––16.1 *13.8––11.6–––––– VPL-A0631M––18.7–15.0–––12.1 *––––9.5 *– VPL-A0632F –23.519.7––15.5 *–––11.9 *––––– VPL-A0633C 32.724.221.3 *––15.0––––––––– VPL-A0751E 30.022.2––16.1 *––––11.2 *––––– VPL-A0752C 31.523.320.5 *–––13.9 *–––––––– VPL-A0752E 31.523.3––16.4 *––––11.8 *––––– VPL-A0753C 32.524.121.5 *–––14.3 *–––––––– VPL-A0753E 32.524.1––17.3 *––––12.4 *––––– VPL-B0631T ––18.7––13.8––––10.5 *–––9.0 VPL-B0631U––18.7––13.8–––11.1––––9.0 VPL-B0632F –23.519.7––15.5 *–––11.9 *––––– VPL-B0632T –––17.4–––12.9–––10.6––9.5 VPL-B0633F –24.220.3–16.3––––12.1 *––––– VPL-B0633M–24.2–17.9–––13.4 *––––10.5 *–– VPL-B0633T ––20.3––15.0––––11.3 *–––9.8 VPL-B0751M––18.6––13.8–––11.2 *––––9.0 VPL-B0752E 31.523.3––16.6 *––––11.8 *––––– VPL-B0752F –23.3–17.3––14.0 *–––––10.0–– VPL-B0752M––19.6––14.5–––11.7 *––––9.5 VPL-B0753E 32.524.1–17.8––––12.5–––––– VPL-B0753F –24.1–17.8––14.7 *––––10.7––– VPL-B0753M––20.2––14.9–––12.4 *––––9.8
