Manual
Table Of Contents
- 1. Description
- 2. Installation
- 3. Associated Cable Selection
- 4. Assembly Pinout Connections
- 4.1. SK1 Connections from module
- 4.2. SK2 Connections from module
- 4.3. SK4 Connections from module
- 4.4. SK5 Connections from module
- 4.5. SK3 Power connection to module
- 4.6. SK6 Power connection to module
- 4.7. TB1 Field Connections
- 4.8. TB2 Field Connections
- 4.9. TB5 Field Connections
- 4.10. TB6 Field Connections
- 4.11. TB3 and TB7 Earth Connection
- 4.12. TB4 Power supply connection
- 4.13. TB8 Power supply connection
- 5. Specifications
Trusted
TM
120Vac Isolated Digital Output FTA T8873
Issue 2 Feb 08 PD-T8873 9
2. Installation
Trusted
TM
16 Channel 120Vac Isolated Digital Input FTA T8873 is designed to be mounted on either of
the TS32 or TS35 DIN rails in the horizontal or vertical positions as required.
3. Associated Cable Selection
Refer to the product descriptions detailed below:
PD-TC000 Trusted
TM
Power Cables
PD-TC200 Trusted
TM
I/O Companion Slot Cables
Note that SmartSlot operation is not available with this FTA.
