Manual
Table Of Contents
- 1. Description
- 2. Installation
- 3. Associated Cable Selection
- 4. Assembly Pinout Connections
- 4.1. SK1 Connections from module
- 4.2. SK2 Connections from module
- 4.3. SK4 Connections from module
- 4.4. SK5 Connections from module
- 4.5. SK3 Power connection to module
- 4.6. SK6 Power connection to module
- 4.7. TB1 Field Connections
- 4.8. TB2 Field Connections
- 4.9. TB5 Field Connections
- 4.10. TB6 Field Connections
- 4.11. TB3 and TB7 Earth Connection
- 4.12. TB4 Power supply connection
- 4.13. TB8 Power supply connection
- 5. Specifications
Trusted
TM
120Vac Isolated Digital Output FTA T8873
Issue 2 Feb 08 PD-T8873 16
5. Specifications
Voltage Range
90 to 150V ac
Maximum Current (Field Supply)
0.5A
P
ower Consumption (Field Supply)
<16W excluding transients
Operating Temperature
-5
0
C to 60
0
C (23
0
F to 140
0
F)
Non-operating Temperature
-25
0
C to 70
0
C (-13
0
F to 158
0
F)
Operating Humidity
5 to 95% RH
Environmental Specifications
Refer to Document 552517
Dimensions
Height
Width
Depth
125mm (4.9ins)
216mm (8.5ins)
69mm (2.7ins)
Weight
700gms (1.5lbs)
