Trusted
TM
120Vac Isolated Digital Output FTA T8873
Issue 2 Feb 08 PD-T8873 13
4.7. TB1 Field Connections
Group Column Service
Ch 1 L1,L2,N
Field device connection channel 1
(2 Balanced Lives ,Neutral)
Ch 2 L1,L2,N Field device connection channel 2
Ch 3 L1,L2,N Field device connection channel 3
Ch 4 L1,L2,N Field device connection channel 4
Table 7 TB1 Connections
4.8. TB2 Field Connections
Group Column Service
Ch 5 L1,L2,N
Field device connection channel 5
(2 Balanced Lives ,Neutral)
Ch 6 L1,L2,N Field device connection channel 6
Ch 7 L1,L2,N Field device connection channel 7
Ch 8 L1,L2,N Field device connection channel 8
Table 8 TB2 Connections
4.9. TB5 Field Connections
Group Column Service
Ch 9 L1,L2,N
Field device connection channel 9
(2 Balanced Lives ,Neutral)
Ch 10 L1,L2,N Field device connection channel 10
Ch 11 L1,L2,N Field device connection channel 11
Ch 12 L1,L2,N Field device connection channel 12
Table 9 TB5 Connections
