120Vac Isolated Digital Output FTA T8873
Issue 2 Feb 08 PD-T8873 10
4. Assembly Pinout Connections
4.1. SK1 Connections from module
Pin Service
1 Channel 1A
2 Channel 1B
3 Channel 2A
4 Channel 2B
5 Channel 3A
6 Channel 3B
7 Channel 4A
8 Channel 4B
Table 1 SK1 Connections
4.2. SK2 Connections from module
Pin Service
1 Channel 5A
2 Channel 5B
3 Channel 6A
4 Channel 6B
5 Channel 7A
6 Channel 7B
7 Channel 8A
8 Channel 8B
Table 2 SK2 Connections
