4. Assembly Pinout Connections
4.1. SK1 and SK2 Connections
The pin connections of SK1 and SK2 are identical and are detailed below:
Row
Pin
A B C
1
2 Not used Not used Not used
3 CH_0_ABC CH_14_AB CH_28_BC
4 CH_0_ABC CH_54_C CH_48_A
5 CH_1_AB CH_15_AB CH_29_BC
6 CH_41_C CH_55_C CH_49_A
7 CH_2_AB CH_16_AB CH_30_BC
8 CN_42_C CH_56_C CH_50_A
9 0V 0V 0V
10 CH_3_AB CH_17_AB CH_31_BC
11 CH_43_C CH_57_C CH_51_A
12 CH_4_AB CH_18_AB CH_32_BC
13 CH_44_C CH_58_C CH_52_A
14 CH_5_AB CH_19_AB CH_33_BC
15 CH_45_C CH_59_C CH_53_A
16 CH_6_AB CH_20_AB CH_34_BC
17 CH_46_C CH_60_C CH_54_A
18 CH_7_AB CH_21_BC CH_35_BC
19 CH_47_C CH_41_A CH_55_A
20 0V 0V 0V
21 CH_8-AB CH_22_BC CH_36_BC
22 CH_48_C CH_42_A CH_56_A
23 CH_9_AB CH_23_BC CH_37_BC
24 CH_49_C CH_43_A CH_57_A
25 CH_10_AB CH_24_BC CH_38_BC
26 CH_50_C CH_44_A CH_58_A
27 CH_11_AB CH_25_BC CH_39_BC
28 CH_51_C CH_45_A CH_59_A
29 CH_12_AB CH_26_BC CH_40_BC
30 CH_52_C CH_46_A CH_60_A
31 CH_13_AB CH_27_BC CH_61_ABC
32
CH_53_C CH_47_A CH_61_ABC
Table 1 SK1 and SK2 Connections
Note: The pin assignments detailed above indicate the mapping of the input channel to the ‘slice’ on
the Trusted
TM
Dual 24V dc Digital Input Module, e.g. channel 39 (pin 27, row C is mapped to
‘slices’ B and C.
