4.9. PL8 Connections
Pin Service
1 Channel 37 24V dc to field device
2 Channel 37 return signal from field device
3 Channel 38 24V dc to field device
4 Channel 38 return signal from field device
5 Channel 39 24V dc to field device
6 Channel 39 return signal from field device
7 Channel 40 24V dc to field device
8 Channel 40 return signal from field device
9 Channel 41 24V dc to field device
10 Channel 41 return signal from field device
11 Channel 42 24V dc to field device
12 Channel 42 return signal from field device
Table 8 PL8 Connections
4.10. PL9 Connections
Pin Service
1 Channel 43 24V dc to field device
2 Channel 43 return signal from field device
3 Channel 44 24V dc to field device
4 Channel 44 return signal from field device
5 Channel 45 24V dc to field device
6 Channel 45 return signal from field device
7 Channel 46 24V dc to field device
8 Channel 46 return signal from field device
9 Channel 47 24V dc to field device
10 Channel 47 return signal from field device
11 Channel 48 24V dc to field device
12 Channel 48 return signal from field device
Table 9 PL9 Connections
