60 Channel 24Vdc Digital Input

- 60 Channel

Introduction

The Trusted

60 Channel 24Vdc Digital Input T8802 is designed to act as the main interface between

a field device generating a digital signal and the Trusted

Dual 24V dc Digital Input Module T8402.

Features

• 60 input channels per FTA.

• Industry standard field device connections (2-wire).

• Standard DIN rail compatibility.

• Simple installation and connection.

• 24V dc operation.

• SmartSlot connection for ‘one to many’ hot replacement of input modules.

• Fused field power supply per channel.

• Additional channels to monitor field supplies (Channels 0 and 61).

Summary of content (16 pages)

PAGE 1
TrustedTM PD-T8802 TrustedTM 60 Channel 24Vdc Digital Input - 60 Channel Introduction TM The Trusted 60 Channel 24Vdc Digital Input T8802 is designed to act as the main interface between TM a field device generating a digital signal and the Trusted Dual 24V dc Digital Input Module T8402. Features • 60 input channels per FTA. • Industry standard field device connections (2-wire). • Standard DIN rail compatibility. • Simple installation and connection. • 24V dc operation.
PAGE 2
TrustedTM 24Vdc Digital Input FTA T8802 Issue Record Issue Number Date Revised by 6 Sep 05 J W Clark Issue 6 Sep 05 Technical Check Authorised by Modification Format PD-T8802 2
PAGE 3
TrustedTM 24Vdc Digital Input FTA T8802 Figure 1 T8802 Photo Issue 6 Sep 05 PD-T8802 3
PAGE 4
TrustedTM 24Vdc Digital Input FTA T8802 Table of Contents 1. Description ...................................................................................................................................7 2. Installation....................................................................................................................................8 3. Associated Cable Selection .........................................................................................................8 4.
PAGE 5
TrustedTM 24Vdc Digital Input FTA T8802 Notice The content of this document is confidential to ICS Triplex Technology Ltd. companies and their partners. It may not be given away, lent, resold, hired out or made available to a third party for any purpose without the written consent of ICS Triplex Technology Ltd. This document contains proprietary information that is protected by copyright. All rights are reserved.
PAGE 6
TrustedTM 24Vdc Digital Input FTA T8802 Revision and Updating Policy All new and revised information pertinent to this document shall be issued by ICS Triplex Technology Ltd. and shall be incorporated into this document in accordance with the enclosed instructions. The change is to be recorded on the Amendment Record of this document.
PAGE 7
TrustedTM 24Vdc Digital Input FTA T8802 1. Description TM The Trusted 60 Channel 24Vdc Digital Input T8802 provides termination for a maximum of 60 input channels from various types of field devices which generate a digital input. Figure 2 below shows the configuration of a single channel. Figure 2 Single Channel Schematic The field supply is derived from dual 24V dc feeds which are ‘commoned’ via diodes on the FTA. The TM supply is then fed to each channel.
PAGE 8
TrustedTM 24Vdc Digital Input FTA T8802 2. Installation TM The Trusted 60 Channel 24Vdc Digital Input T8802 is designed to be mounted on either of the TS32 or TS35 DIN rails in the horizontal or vertical positions as required. 3.
PAGE 9
TrustedTM 24Vdc Digital Input FTA T8802 4. Assembly Pinout Connections 4.1.
PAGE 10
TrustedTM 24Vdc Digital Input FTA T8802 4.2. PL1 Connections Pin Service 1 24V-1V 2 0V 3 0V 4 24V-2 Table 2 PL1 Connections 4.3.
PAGE 11
TrustedTM 24Vdc Digital Input FTA T8802 4.5.
PAGE 12
TrustedTM 24Vdc Digital Input FTA T8802 4.7.
PAGE 13
TrustedTM 24Vdc Digital Input FTA T8802 4.9.
PAGE 14
TrustedTM 24Vdc Digital Input FTA T8802 4.11. PL10 Connections Pin Service 1 Channel 0 2 Channels 61 Table 10 PL10 Connections 4.12.
PAGE 15
TrustedTM 24Vdc Digital Input FTA T8802 5.
