Instruction Manual
Table Of Contents
- 1. Description
- 2. Installation
- 3. Application
- 3.1. Message Forwarding
- 3.2. Control Signal Forwarding
- 3.3. Interface Module Selection
- 3.4. IMB Power Generation
- 3.5. IMB Clock Generation
- 3.6. 24V Supply Monitoring
- 3.7. Module Information
- 3.8. Communication Busses
- 3.9. Module Configuration
- 3.10. I/O Complex Equipment Definition T8310
- 3.11. System Initialisation File
- 4. Operation
- 5. Fault Finding and Maintenance
- 6. Specifications
Trusted
TM
Module T8310
Issue 12 Dec 06 PD-T8310 27
6. Specifications
Voltage Range
20 to 32V dc
Maximum Load
40W
Heat Dissipation
40W
Use with Chassis
T8300
Module Clocks
50MHz
Expander Bus Data Rate
250Mbps
I/O Interface
Expander Chassis backplane
Expander Comms Max Distance
Using TC-301 copper cable
Using fibre converters
30m
10km
Operating Temperature
-5°C to 60ºC (23°F to 140°F)
Non-operating Temperature
-25°C to 70ºC (-25°F to 158°F)
Operating Humidity
5 to 95% RH
Environmental Specifications
Refer to Document 552517
Dimensions
Height:
Width
Depth:
266mm (10.5ins)
31mm (1.2ins)
303mm (12.0ins)
Weight
1.33kg (2.9lbs.)
