Trusted
TM
Module T8310
Issue 12 Dec 06 PD-T8310 14
2.5. Expander Chassis Bus Connector (PL4)
PL4 is a 96-way DIN41612, C-type connector.
CONNECTOR PL4 PINOUT
Pin
A B C
1 TXA+
2 TXA-
3
4
5 RXA1+ LB_A_ACTN/STB_OUT
6 RXA1- LB_A_ACTN/STB_IN
7
8
9
10
11 GND GND GND
12 TXB+
13 TXB-
14
15
16 RXB1+ LB_B_ACTN/STB_OUT
17 RXB1- LB_B_ACTN/STB_IN
18
19
20
21
22
23 TXC+
24 TXC-
25
26
27 RXC1+ LB_C_ACTN/STB_OUT
28 RXC1- LB_C_ACTN/STB_IN
29
30
31
32
Table 2 PL4 Pinout Connections
