Power Supply System T82xx
Issue 9 Mar 06 PD-T82xx 8
1.2. Power Supply Modules
The power supply assembly modules are single (if redundant inputs are not required) and dual input,
hot swap, user-replaceable ac and dc units. Table 2 identifies the available types of modules.
Catalogue
No.
Input
Type
Input Power
Voltage
Output Power
Voltage
T8220 Dual 110-240V ac 15V dc
T8222 Dual 24V dc 15V dc
T8223 Single 110-240V ac 24V dc
T8224 Single 110-240V ac 15 V dc
T8225 Dual 110-240V ac 24V dc
T8226 Dual 24V dc 24V dc
Table 2 Module Types
The dual inputs on the ac modules are galvanically isolated from each other. The inputs on the dc
modules are diode isolated and share a common return.
