5. Specifications
Voltage Range
T8220, T8223, T8224, T8225
T8222, T8226
85V ac to 264V ac
20V dc to 32V dc
Frequency Range
T8220, T8223, T8224, T8225 47Hz to 63Hz
Inrush Current (120/260V ac)
T8220, T8223, T8224, T8225
20/40A (peak) Cold, 35/65A
(peak) Hot
Power Factor 0.95 min.
Efficiency 70%
Use with Chassis:
T8220, T8223, T8224, T8225
T8222, T8226
T8200
T8202
Fusing (Internal to module)
T8220, T8223, T8224, T8225
T8222, T8226
6A, 250V, 3AG Slow Blow
20 A, 250V, 3AB Slow Blow
Output Voltage
T8220, T8222, T8224,
T8223, T8225, T8226
+15V dc
+24V dc
Output Power 250W, per module
Power Hold-up Time
T8220, T8223, T8224, T8225
T8222, T8226
20ms, minimum
1ms, minimum
Operating Temperature –5
0
C to 60
0
C (23
0
to 140
0
F)
Non-operating Temperature -25
0
to 70
0
C (-25
0
to 158
0
F)
Operating Humidity
5 to 95% RH
Environmental Specifications Refer to Document 552517
Module Dimensions
Height:
Width:
Depth:
266mm (10.47in)
61mm (2.38in)
318mm (2.5in)
Chassis Dimensions
Height:
Width:
Depth:
266mm (10.47in)
483mm (19in)
343mm (13.5in)
Module Weight 3.25kg (7.2lbs)
Chassis Weight 7kg (15.4lbs)
