Manual

C-2
SD3100 Power Modules
C.3 Spare Parts Kits
Type of Kit
Current
Code
1
1. R = 1250A, S = 1650A, T = 3000A.
460 VAC 575 VAC 660 VAC Brief Description
Line RC Suppressor
(Option 14LSP)
R,S,T 2300-SPB01A 2300-SPB01A 2300-SPB02A 1 PCB with 2 sets of fuses
Air Flow Switch PCB
(Option 14AFL)
R,S 2300-SPP01A 2300-SPP01A 2300-SPP01A 1 PCB with 0.5A power supply
T 2300-SPP02A 2300-SPP02A 2300-SPP02A 1 PCB with 1.1A power supply
Air Flow Switch
(Option 14AFL)
R,S 2300-SPK03A 2300-SPK03A 2300-SPK03A
T 2300-SPK01A 2300-SPK01A 2300-SPK01A
Line MOVs R,S,T 2300-SPJ02A 2300-SPJ03A 2300-SPJ04A 1 set
Armature SCRs
R 2361-SPG01A 2361-SPG01A 2361-SPG01A 2 SCRs
S 2361-SPG02A 2361-SPG02A 2361-SPG02A 2 SCRs
T 2361-SPG03A 2361-SPG03A 2361-SPG03A 2 SCRs
Positive (Top)
Regenerative Armature
Assemblies
R SD3100-SPA01A SD3100-SPA01A SD3100-SPA01A
S SD3100-SPA05A SD3100-SPA05A SD3100-SPA05A
T 2361-SPA05A 2361-SPA05A 2361-SPA05A
Negative (Bottom)
Regenerative Armature
Assemblies
R SD3100-SPA02A SD3100-SPA02A SD3100-SPA02A
S SD3100-SPA06A SD3100-SPA06A SD3100-SPA06A
T 2361-SPA06A 2361-SPA06A 2361-SPA06A
Positive (Top) Non-
Regenerative Armature
Assemblies
R SD3100-SPA03A SD3100-SPA03A SD3100-SPA03A
S SD3100-SPA07A SD3100-SPA07A SD3100-SPA07A
Negative (Bottom) Non-
Regenerative Armature
Assemblies
R SD3100-SPA04A SD3100-SPA04A SD3100-SPA04A
S SD3100-SPA08A SD3100-SPA08A SD3100-SPA08A
Bridge Fan
R,S 2361-SPH01A 2361-SPH01A 2361-SPH01A
T 2361-SPH02A 2361-SPH02A 2361-SPH02A
Bridge Fan Door Filter T 2361-SPK02A 2361-SPK02A 2361-SPK02A
Fiberglass 20” x 30” x 1”, 1
required, 6 per kit.
Slide-In Fan T 2361-SPH03A 2361-SPH03A 2361-SPH03A
Loose Power Fuses
R 2361-SPE08A 2361-SPE08A 2361-SPE08A
2 fuses per kit
2
2. Drive requires 12 fuses.
S 2361-SPE09A 2361-SPE09A 2361-SPE09A
2 fuses per kit
2
T 2361-SPE10A 2361-SPE10A 2361-SPE10A
3 fuses per kit
3
3. Drive requires 18 fuses.
Power Fuse Assembly T 2361-SPE11A 2361-SPE11A 2361-SPE11A
1 assembly containing 3 fuses in
parallel
Input Line Fuses
R 2361-SPE12A 2361-SPE12A 2361-SPE12A
S 2361-SPE13A 2361-SPE13A 2361-SPE13A
T 2361-SPE14A 2361-SPE14A 2361-SPE14A
Snubber Assembly
R 2361-SPB03A 2361-SPB03A 2361-SPB03A
S 2361-SPB01A 2361-SPB01A 2361-SPB01A
T 2361-SPB02A 2361-SPB02A 2361-SPB02A
