Replacement Parts
C.1 Regulator Assembly
Please refer to the following instruction manuals for replacement parts information:
C.2 Field Power Module Replacement Parts
Component Manual Number
PMI Rack and Modules S-3008
Parallel Gate Amplifier Rack and
Modules
S-3045
15 Amp, S2R Field Power Module (#805405-3R)
Description Part Number
AC Input Line Fuses (2) 64676-3CL
Power Cubes (3)
FPC1 (1,2,3,4 THY)
RPC1 (11,12,13,14 THY)
CLAMP (Q1,Q2)
701819-303AW
Field Gate Coupling Card B/M O-60014 - ∗∗
Hall Device Assembly 615051-R
PMI Cable
1
1. Specify cable length in inches
∗∗
Revision level
612418-S
60 Amp, S2R Field Power Module (#805405-5R)
Part Description Reliance Part Number
AC Input Line Fuses (2) 64676-130ASX
Power Cubes (5):
(FPC1 - 1,4THY)
(FPC2 - 3,6THY)
(RPC1 - 11,14THY)
(RPC2 - 13,16THY)
(CLAMP - Q1,Q2)
701819-201AW
Field Gate Coupling Card B/M 60033-∗∗
Snubber P.C. Board B/M 60034-∗∗
Gate Pin Extension (10) 615050-15R
37 (+) Cable Assembly 805417-R
PMI Cable
1
1. Specify required length in inches.
∗∗
Revision level
