Technical Specifications
A-13
A.6 Field Power Module Specifications
Ambient Conditions
•
Storage temperature: -40 to 85° C (-40 to 185° F)
•
Operating temperature: 0 to 40° C (32 to 104° F)
•
Humidity: 5 to 95%, non-condensing
•
Altitude: Up to 1000 meters (3300 feet) without derating output power. For every
91.4 meters (300 feet) above 1000 meters, derate the output current 1%.
Enclosure
•
Enclosed chassis with all circuits covered and protected.
Cooling
•
Convection cooled.
Dimensions
Input Ratings
•
AC field input voltage: 230 to 460 VAC +/- 10%, continuous operation
•
AC line frequency: 48 to 62 Hz.
•
Source rating: 2 kVA to 30 kVA
•
Maximum short circuit current: 10kA
•
Internal field fuse rating:15A unit: 20A, 600V
60A unit: 90A, 700V
•
One minute overload: 150% of maximum current (once per hour)
Output Ratings
Additional Information
For additional information on DPS single-phase Field Power Modules, refer to
instruction manual S-3060.
Part Number Height Width Depth
805405-3R 340 mm (13.4 in) 128 mm (5 in) 127 mm (5 in)
805405-5R 523 mm (20.6 in) 180 mm (7.1 in) 220 mm (8.7 in)
Part Number AC Input
Maximum
Rated Power
Rated Current
@ 40º C
1
1. Maximum ambient temperature with a 15° C internal maximum temperature
(Minimum Field Power Module ambient: 55° C)
805405-3R (S2R) 460V 15kW 15A
805405-5R (S2R)
230V 12kW 60A
460V 24kW 60A
