SD3100 Power Modules
A.4 3000A Power Module Specifications
The following table of specifications applies to the 3000A Power Module
Height
91.5” (2324 mm)
1
1. Note that A 20”-high tophat assembly (which mounts over the disconnect bay), is
included with each 3000A Power Module.
Width 95” (2413 mm)
Depth 20” (508 mm)
MCC Sections 4
Shipping Weight 3500 lbs (1588 kg)
Operating Sound Level 82 dB, wt. A
Table A.3 – Electrical Specifications (3000A Power Module)
Input Output
Nominal
Input Voltage
(VAC)
Input Power
(kVA)
Armature
Voltage
(VDC)
Armature
Current
(ADC)
Field Voltage
(VDC)
Field Current
(ADC) Nominal HP
460 1374 500 2000
Dependent on options
selected. Refer to
section A.6.
1250
460 1634 500 2400 1500
460 2024 500 3000 1750
575 1713 600 1995 1500
575 1985 600 2330 1750
575 2254 600 2660 2000
575 2531 600 3000 2250
660 1705 700 1715 1500
660 1971 700 2000 1750
660 2242 700 2290 2000
660 2508 700 2575 2250
660 2905 700 3000 2500
