Technical Specifications
A-5
A.3 1650A Power Module Specifications
The following specifications apply to the 1650A Power Module.
Height
91.5” (2324 mm)
1
1. Note that the height of the 1650A Power Module includes a 1.5”-high base
channel.
Width 75” (1905 mm)
Depth 20” (508 mm)
Shipping Weight 2500 lbs (1134 kg)
MCC Sections 3
Operating Sound Level 83 dB, wt. A
Table A.2 – Electrical Specifications (1650A Power Module)
Input Output
Nominal
Input Voltage
(VAC)
Input Power
(kVA)
Armature
Voltage
(VDC)
Armature
Current
(ADC)
Field Voltage
(VDC)
Field Current
(ADC) Nominal HP
460 867 500 1280
Dependent on options
selected. Refer to
section A.6.
800
460 972 500 1440 900
460 1108 500 1650 1000
575 1125 600 1330 1000
575 1385 600 1650 1250
660 1590 700 1650 1250
