SD3100 Power Modules
A.2 1250A Power Module Specifications
The following specifications apply to the 1250A Power Module.
Height
91.5” (2324 mm)
1
1. Note that the height of the 1250A Power Module includes a 1.5”-high base channel.
Width 75” (1905 mm)
Depth 20” (508 mm)
Shipping Weight 2500 lbs (1134 kg)
MCC Sections 3
Operating Sound Level 83 dB, wt. A
Table A.1 – Electrical Specifications (1250A Power Module)
Input Output
Nominal
Input Voltage
(VAC)
Input Power
(kVA)
Armature
Voltage
(VDC)
Armature
Current
(ADC)
Field Voltage
(VDC)
Field Current
(ADC) Nominal HP
460 750 500 1100
Dependent on options
selected. Refer to
section A.6.
700
460 848 500 1250 750
575 856 600 1000 750
575 909 600 1065 800
575 1060 600 1250 900
660 796 700 800 700
660 852 700 860 750
660 904 700 915 800
660 1011 700 1030 900
660 1217 700 1250 1000
