Mechanical/Electrical Description
2-5
The non-regenerative bridge is shown in figure 2.3. Cell fuses protect the thyristors in
the event of a bridge failure.
Figure 2.3 – Armature Bridge (Non-Regenerative)
A1
Armature
Voltage
3-Phase
AC
Input
Main
Contactor
A2
SNUBBER
SNUBBER
SNUBBER
SNUBBER
SNUBBER
SNUBBER
