Replacement Parts
C-5
1457 Amp SA3000 Power Module
Table C.15 – 1457A SA3000 Power Module
Part Description
1
1. Components are identified in figure 2.3.
Quantity
Rockwell
Part Number
Blower Assembly 3 850011-R
IGBT Phase Module Assembly 9 803430-8S
Capacitor Bank Assembly 3 803430-6S
Pre-charge Assembly 3 850022-3_
115 VAC Power Supply Assembly 1 850100-3_
Disconnect Switch (Optional) (600A, 1000 VAC) 1 65242-8B
Fuse (FPM A,B) (F101A,B / F102A,B)
(1000A,1000VAC)
6 64676-80P
Local Power Interface Module 1 0-60027
250VA Isolation Transformer (250 VA, 110 VAC) 1 417155-16B
PMI Rack Assembly 1 805401-5R
25KHz Power Supply (2A)
(115 VAC input, 60 VDC output)
1 802268-16R
LEM Sensor (1000A, 5000:1) 9 600595-18A
Reactor Assembly (600A, 7.5mH) 3 850022-5R
Ω 3 63481-102TFB
DC Feedback Module 1 0-55350-10
Motor Ammeter (Optional) 1 708208-20R
Motor Voltmeter (Optional) 1 708208-18R
Torque Meter (Optional) 1 708208-17R
Frequency Meter (Optional) 1 708208-19R
Blower Filter 3 69470-3RM
Table C.16 – Capacitor Bank Assembly (803430-6S)
Part Description Quantity
Rockwell
Part Number
Capacitor (7200µF, 500 VDC) 18 600442-30SX
Table C.17 – Blower Assembly (850011-R)
Part Description Quantity
Rockwell
Part Number
Blower (115 VAC) 1 69739-47R
Starter Capacitor (40µF, 240 VAC) 1 69932-24QQ
