High Power SA3000 Power Modules

972 Amp SA3000 Power Module (Continued)

Table C.11 – Pre-charge Assembly (850022-3_)

Part Description

Quantity

Rockwell

Part Number

Ω 10 63481-6V

Contactor (230A, 600 VAC) 1 705310-39BX

Pre-charge Module 1 0-55350-4

Pre-charge Capacitor (4700µH, 50 VDC) 1 600442-31TS

Pre-charge Resistors (3.819Ω) 2 48627-G

Voltage Feedback Module 1 O-55350-10

Table C.12 – 115 VAC Power Supply Assembly (850100-3R, -3S)

Part Description

Quantity

Rockwell

Part Number

1 704323-33K

115 VAC Circuit Breaker (25A, 600 VAC) 1 or 2 91212-4RA

24 VDC Power Supply (2A) 2 704323-32G

Fuse (1FU) (5A, 600 VAC) 1 64676-29R

Fuse (3FU) (3.2A, 600 VAC) 1 64676-29P

Table C.13 – IGBT Phase Module Assembly (803430-8S)

Part Description Quantity

Rockwell

Part Number

IGBT Transistor (600A, 1200 VDC) 4 423402-4S

Warning Thermostat 1 66012-16A

Fault Thermostat 1 66012-16B

Gate Driver/Snubber Module 1 0-55350-15

Fuse (F103A, F104A, F105A) (630A, 1000 VAC) 3 64676-79AZ

Table C.14 – PMI Rack Assembly (805401-5)

Part Description

Quantity

Rockwell

Part Number

Power Supply 1 0-60007-2

Processor Module 1 0-60021-1

Resolver Module 1 0-60031-4

AC Technology Module 1 0-60023-3

AC Parallel Interface Module 1 0-60029-1

Gate Driver Interface Module 2 0-60028-1
